Micro Controller

Name: Micro Controller
Brand: RHYTHM SEMICONDUCTORS

Get a Price/Quote

MOQ : 1000 Pieces

Micro Controller Specification

Interface
UART, SPI, I2C, GPIO

Resolution
10-bit ADC

Processor Speed
16 MIPS

Thermal Conductivity
Low, suitable for air-cooled enclosures

Power Supply
External DC power

Output
Digital and analog outputs via GPIO/MPLS

IP Rating
Not IP rated (dependent on enclosure)

Display Type
No onboard display (supports external LCD/LEDs)

Operating Temperature
-40C to +85C

Response Time
< 10 s (input to output)

Input
Digital and analog inputs via GPIO pins

Charging Voltage
Not applicable (powered by DC)

Components
Microcontroller IC, crystal oscillator, voltage regulator

Sensors Specification
Supports connection to various external digital/analog sensors

Power Source
DC Adapter or USB

Features
Programmable, Low-Power Consumption, Compact Size, ESD Protection

Usage
Embedded system development, automation

Product Type
Micro Controller

Application
Robotics, Industrial Automation, Consumer Electronics

Rated Voltage
5V DC

Supply Voltage
3.3V - 5V DC

Size
Standard IC package size

Dimension (L*W*H)
50 mm x 30 mm x 2 mm

Function
Microcontroller for digital and analog signal processing, data storage, and device interfacing

Color
Black

Weight
30 g

Current Rating
Up to 500 mA

Capacity
32 kB Flash Memory, 2 kB SRAM

Thickness
2 mm

Frequency
16 MHz

ADC Channels
6

Mounting Type
Through hole or SMD

Programming Method
ISP (In-System Programming), serial, bootloader

EEPROM Size
1 kB

Protection
Reverse polarity and overcurrent protection

Clock Type
External crystal oscillator

PWN Channels
4

Compatibility
Compatible with Arduino IDE and other microcontroller ecosystems

Supported Languages
C/C++, Assembly

GPIO Pins
20

RoHS Compliance
Yes

Package Type
DIP/SMD

Micro Controller Trade Information

Minimum Order Quantity
1000 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
10000 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Micro Controller

Experience the laureate of embedded technology with our customizable microcontroller-an in-demand solution for modern automation, digital signal processing, and device interfacing. Featuring unparalleled versatility, this black, compact microcontroller boasts 20 GPIO pins, 6 ADC channels (10-bit resolution), 4 PWM channels, and 32kB Flash. Compatible with the Arduino IDE and other major platforms, it supports both DIP/SMD mounting and ISP/serial/bootloader programming. Reverse polarity and overcurrent protection provide unmatchable device safety. RoHS compliant and suitable for industrial, robotics, and consumer electronics, add to cart for superior, reliable performance.

Microcontroller Applications and Usage Highlights

This microcontroller excels in robotics, industrial automation, and consumer electronics development. Used as the core processing unit, it manages digital and analog signal acquisition, device interfacing, and real-time data storage. Suitable for embedded system development, its adaptable interfaces (UART, SPI, I2C) and flexible mounting options make it ideal for prototyping and mass production. With support for both C/C++ and Assembly, engineers and students alike can harness its power for rapid prototyping or deployment in commercial solutions.

Export Markets, Domestic Demand, and Supply Capacity

Our laureate microcontroller enjoys robust demand across international and Indian markets, serving manufacturers, suppliers, and educational institutes. Delivered efficiently across Europe, South Asia, and the Middle East, orders are processed promptly upon receipt of a purchase order, with shipment managed to ensure secure, timely arrival. With high supply ability, we accommodate small and bulk orders, ensuring consistent stock for ongoing development projects as well as large-scale manufacturing ventures.

FAQ's of Micro Controller:

Q: How is the microcontroller programmed and what methods are supported?

A: The microcontroller supports flexible programming via ISP (In-System Programming), serial interface, and bootloader, making it easy to update firmware or integrate into various embedded systems using either C/C++ or Assembly language.

Q: What are the main benefits of using this microcontroller for automation applications?

A: Its unparalleled combination of digital/analog I/O, robust EEPROM, and compatibility with Arduino IDE enable seamless integration, reliable processing, and customizable performance, making it ideal for automation and robotics projects.

Q: When should I use through hole mounting compared to SMD mounting?

A: Through hole mounting is ideal for prototyping and environments requiring mechanical strength, while SMD mounting is recommended for compact designs and automated assembly, optimizing space and production efficiency.

Q: Where can I connect external displays or sensors to this microcontroller?

A: You can connect digital and analog external sensors through the GPIO and ADC pins. For external displays, interface via supported pins and communication protocols, such as UART, SPI, or I2C.

Q: What protection features are included in this microcontroller?

A: The device offers reverse polarity and overcurrent protection, ensuring safe operation and reducing risk of component damage during development and usage.

Q: How do I process analog inputs using this microcontroller?

A: Analog inputs are handled through six dedicated ADC channels, each with 10-bit resolution, enabling precise acquisition of analog signals from sensors or other devices.
